Flag BG

Specification

Alucosite Factory
Alucosite Factory

White Core FR

color catalog icon

Unbreakable

color catalog icon

(FR) BB Class

color catalog icon

(FR) AA Class

Alucosite Factory

Grey Standard Core

color catalog icon

Unbreakable

color catalog icon

Breakable

color catalog icon

FR

color catalog icon

Non FR

Alucosite Factory

Black Standard Core

color catalog icon

Unbreakable

color catalog icon

Non FR

ISO logos

Physical Properties

check icon

Thickness of Composite Panel

4.0 - 5.0 mm

check icon

Core

Unbreakable Polyethylene / FR

check icon

0.2% Proof Stress (Rp.0.2)

≥ 95

check icon

Minor Surface Coating Flaws

≤ 3/m2

check icon

Thickness of Aluminium Skin Coil

0.3 - 0.5 mm

check icon

Coating Paint

PVDF “Color Way”

check icon

Elongation A50

≥6% (GL50 mm)

check icon

Peel Strength

22.3 kgf/mm2

check icon

Thickness of Coating

18 - 35 Micro

check icon

Temper

H22/H42

check icon

Rigidity (EJ KN cm2/m)

4.5mm = 2800

check icon

Yield Strength

12.9 kgf/mm2

check icon

Aluminium Alloy

3003/5005

check icon

Tensile Strength of Aluminium Skil Coil

≥ 140

check icon

Modulus of Elasticity (N/mm2)

70.000 N/mm2

check icon

Standard Size of Each Sheet

1220mm x 4880mm / Sheet

Variant Specification

Alucosite Stretch Icon

Commercial Grade Series

ALUCOSITE's Commercial Grade Series offers budget-friendly solutions without sacrificing quality. Tailored for projects with financial constraints, it maintains commendable performance using economical base materials.

Alucosite Stretch Icon

Regular Grade Series

For small and low-rise buildings, ALUCOSITE's Regular Grade Series offers superior quality. Crafted from aluminum coil type 3003 for excellent bending resistance, it elevates structures with reliability and aesthetic appeal.

Alucosite Stretch Icon

High Grade Series

ALUCOSITE's High Grade Series, ideal for medium to high-rise buildings, uses aluminum coil 3003 with a 28-micron coating for lasting color resistance. Equipped with Fire Retardant (FR) properties, it adds safety layers.

Alucosite Stretch Icon

Prime Grade Series

Exclusively for high-rise buildings, ALUCOSITE's Prime Grade Series features aluminum coil 5005 for exceptional bending. With Fire Retardant (FR) properties, it prioritizes safety while elevating architectural projects with superior strength.

Alucosite Stretch Icon

Extra Prime Series

ALUCOSITE's Extra Prime Series, a premium product with 5.0 mm thickness and 35-micron coating, is tailored for high horizontal pressure resistance. Exclusively made with Fire Retardant (FR) core, it ensures non-flammability, elevating structures with unparalleled strength.
